We are a precision manufacturer specializing in precision metal hardware components, and we proudly introduce our Carbon Steel CNC Turning Parts: Shaft Pin. Specifically designed for use in soundproof wall assemblies, this shaft pin is expertly crafted from high-quality 1045 carbon steel material. It features specifications of Φ16×2500(Φ16×60)mm, making it an ideal choice for various soundproofing applications.
| Items | Details |
| Product Name | Nonstandard machining customized carbon steel cylindrical pin with hole, headless single-hole terminal pin shaft end bar |
| Standard Compliance | OEM Service |
| Certifications | IATF16949 2016; ISO9001 2015; ISO14001:2015; RoHS; REACH |
| Manufacturing Process | CNC Turning, Drilling, Grinding |
| Applications | Machinery, Automotive, Industrial Equipment, Jigs and Fixtures |
| Product Type | Precision Nonstandard Parts (OEM Service) |
| Material Options | Carbon Steel (e.g. AISI 1045, 1060) |
| Packaging Details: | Individually wrapped in VCI paper, then placed in plastic boxes with dividers, finally packed in carton boxes, or as per clients' specific requirements. |
| Diameter Range | Φ16(Φ16×60) |
| Length Range | 10mm - 200mm |
| Hole Diameter Range | 1mm - 10mm |
| Tolerance:Outer Diameter,Length,Hole Diameter | ±0.01mm,±0.05mm,±0.02mm |
| Hardness | 20-30 HRC (can be heat treated to 45-55 HRC) |
| Surface Finish | Ra 0.4-1.6μm |
| Straightness | 0.02mm/100mm |
| Surface Treatment Options | Spray anti-rust oil,Black oxide, Phosphating, Zinc plating |
| Color | Natural steel color or as per surface treatment |
| Machining Capabilities | CNC Turning, Drilling, Grinding, Heat Treatment |
| Special Features | High precision single hole, Customizable hole position and depth, Good wear resistance, Suitable for various assembly and alignment applications, Heat treatment available for increased hardness |
| Services | Items | Details |
| Shipping Port | Shenzhen or Hong Kong | |
| Production Lead Time | Quantity (pieces) 1 - 5,000 | 12 days |
| Quantity (pieces) > 5,000 | To be negotiated | |
| Customization Services | Customized dimensions | Min. order 50 |
| Special hole configurations | Min. order 100 | |
| Heat treatment | Min. order 20 |
